REVOLUTION III 850 Watt 80 PLUS Gold Fully Modular ATX 3.1 Power Supply

▪ Integrated with Intel ATX 3.1
▪ Fully Modular 80 PLUS® Gold Certified
▪ One 600W Native 12V-2x6 Cable Included
▪ Industrial-Grade 100% Japanese Capacitors
▪ Ultra Quiet 120mm FDB Fan
▪ Mesh-sleeved Cables with 21 pcs Cable Comb Kit

COMPARE Compare List (0)
REVOLUTION III
REVOLUTION III
REVOLUTION III logo

THE LEGEND OF POWER SUPPLY

REVOLUTION III Features icon
revolution III 80-PLUS

80 PLUS® GOLD CERTIFIED

REVOLUTION III 850W power supply is 80 PLUS® Gold certified with efficiency up to 93% on standard loading.

ATX 3.1 READY

REVOLUTION III 850W power supply meets the Intel ATX 3.1 standards to ensure top-notch performance of power hungry graphics cards.

2X Total Power Excursion
3X GPU Power Excursion
revolution III ATX 3.1 READY
revolution III 100% JAPANESE CAPACITORS

100% JAPANESE CAPACITORS

REVOLUTION III 850W power supply incorporates 100% industrial-grade Japanese capacitors with high-quality materials and manufacturing processes, ensuring stable and consistent performance.

FLUID DYNAMIC BEARING FAN

The F.D.B. (Fluid Dynamic Bearing) fan delivers a quiet operation while maintaining the cooling performance.

revolution III Fan

CERTIFIED FOR OPERATION AT 5000M ALTITUDE AREA

REVOLUTION III 850W power supply is designed with high-quality components and optimized layout for superior insulation and cooling performance. It can continually operate at 40°C and at altitudes up to 5,000 meters, making it suitable for a wide range of environments.



revolution III PREMIUM MESH-SLEEVED CABLES

PREMIUM MESH-SLEEVED CABLES

The REVOLUTION III 850W power supply features premium individually mesh-sleeved cables with cable combs for a clean and organized build. The modular sockets, inclined to one side, offer effortless cable routing and management.

HEAVY-DUTY INDUSTRIAL-GRADE PROTECTIONS

  • CyberbronII power supply with protection mechanism icon-1

    Over Current
    Protection

  • CyberbronII power supply with protection mechanism icon-2

    Over Voltage
    Protection

  • CyberbronII power supply with protection mechanism icon-3

    Under Voltage
    Protection

  • CyberbronII power supply with protection mechanism icon-3

    Over Power
    Protection

  • CyberbronII power supply with protection mechanism icon-4

    Over Temperature
    Protection

  • CyberbronII power supply with protection mechanism icon-5

    Short Circuit
    Protection

CABLE AND POWER AS YOU NEED

Only connect the cable you need with fully modular design

Model Name ERV650G-AHG-MAC
ERV650G-AHG-MAV		 ERV750G-AHG-MAC
ERV750G-AHG-MAV		 ERV850G-AHG-MAC
ERV850G-AHG-MAV		 ERV1000G-AHG-MAC
ERV1000G-AHG-MAV
Wattage 650W 750W 850W 1000W
ATX Motherboard 24
(20+4)Pin / 60cm		 revolution III power supply cables icon-1 1 1 1 1
CPU 4+4Pin
/ 65cm		 revolution III power supply cables icon-2 0 1 1 2
CPU (4+4)Pin+(4+4)Pin
/ 60+15cm		 revolution III power supply cables icon-3 1 1 1 0
PCIE (6+2)Pin
/ 60cm		 revolution III power supply cables icon-4 0 1 1 1
PCIE (6+2)Pin+(6+2)Pin
/ 55+15cm		 revolution III power supply cables icon-5 1 1 1 0
12V-2x6 (12+4)Pin
/ 60cm		 revolution III power supply cables icon-6 1
(450W)		 1
(600W)		 1
(600W)		 1
(600W)
3*SATA+4P Molex
/ 45+15+15+15cm		 revolution III power supply cables icon-7 2 3 3 3
12V-2x6 to 2*PCIe(6+2)P
/ 60cm		 revolution III power supply cables icon-8 0 0 0 1

Dimensions

Unit: mm

REVOLUTION III dimension
REVOLUTION III 850W
Motherboard 24 (20+4) pin 1
[ 1x 60cm ]
CPU 4+4 Pin 1
[ 1 x 65cm ]
CPU (4+4)+(4+4) Pin 2
[ 1 x 60/15cm ]
12V-2x6 12+4 pin 1
[ 1 x 60cm ]
PCIe 6+2pin 1
[ 1 x 60cm ]
PCIe (6+2)+(6+2) Pin 2
[ 1 x 55+15cm ]
3*SATA + 4P Molex 9+3
[ 3 x 45/15/15/15cm ]
Notice:

For users looking to put in a high-end, power-demanding GPU, please plug in the 12+4P / 6P / 6+2P PCIe connector(s) from your ENERMAX power supply to the GPU properly. This will prevent the motherboard from overloading and possibly causing any damage to your system, including your ENERMAX power supply. Once this occurs, it will be treated as improper system configuration, and any damage caused to the power supply, as a result, will not be covered under ENERMAX manufacturer’s warranty. Please refer to your motherboard & GPU’s user manuals to configure your system properly to prevent the motherboard from overloading and causing any damage to your system and your power supply.

The modular cables in the box are all compatible with your newly purchased power supply. Please only use the modular cables provided in your ENERMAX power supply package. Do NOT use other modular cables to prevent pin configuration damage to your system and your power supply.

Info for the rated current of the DC cables: The safety current is 6A per single DC wire. Please note that overloading may cause the connectors or wires meltdown and could void the warranty.


80 PLUS Efficiency Gold
Modular Fully Modular
Cable type Individually Mesh-Sleeved Cable
Total power (W) 850
Input Voltage (V) 100-240
Input Current (A) 10-6
Input Frequency (Hz) 50-60
Fan size (mm) 120
Operating temperature (°C) 40
MTBF (hours) >100K
Protection OCP, OVP, UVP, OPP, OTP, SCP
Dimension (D x W x H), (mm) 140 x 150 x 86
+3.3V(A) 20
+5V(A) 20
+12V1(A) 70.8
-12V(A) 0.4
+5Vsb(A) 2.5
Combined Wattage 12V (W) 849.6
Combined Wattage 3.3V + 5V(W) 100
EAN code 4713157728883 / 4713157728890
UPC code 819315028889 / 819315028896
Box dimensions (D x W x H), (mm) 310 x 190 x 110
Gross Weight / unit (kg) 1.6
